Detailed description
The automatic wire and cable winding tying machines are innovative devices that have revolutionized the way we handle wires and cables. These machines are designed to simplify the process of bundling, winding, and tying wires.
Technical parameters:
The appearance of winding Cable The distance between winding cables is 80-160mm
The suitable wire diameter of 3-6mm. Suitable length 1-10m
The head length is 0-400mm and the tail length is 100-280mm
Binding iron cores with a diameter ≤40mm using cable ties
Machine efficiency ≤1000PCS/H bearing capacity of cable ties ≤7.5KG
Machine size about 1200W*850D*1600Hmm Machine power 2.5KW
Machine weight: about 230KG
Main components:
Cylinder: Yadeke cylinder and solenoid valve,
Winding motor: servo motor 1000W Turbot
Line-taking translation motor: servo motor 750W Turbot
Tie belt conveying motor: step motor thunder race
Twisting tie belt motor: step motor thunder race
Take line translation: double slider
PLC: Fengwei Screen: Maintenance control
Frame: iron frame power supply: bright weft
Grating: Pubang Manual start: dual start
relay
Features:
 safety protection type, loop the middle figure 8 and tie a tie;
 applies USB/DC/AC line, which allows the head and tail to be retained, and the head and tail to be retained.
 winding motor uses a 1000W servo, powerful and more stable.
 takes line translation motor 750W servo, eliminates step loss of stepping motor, and the translation is more stable.
 tie belt provides a load capacity of 7.5kg, which reduces the frequency of changing the tie belt and improves working efficiency.
 spit tie belt structure adds a single button, convenient installation and debugging;
 The rubber band's lowers claw structure is optimized to make the rubber band more resistant to wear and convenient for installation and commissioning.
 twisted wire claw, takeout wire claw, and lower claw are connected with stainless steel, which is more stable and beautiful.
 production efficiency can reach 1500 bars/hour, saving labor;
 simple and easy to operate, debug, and maintain;
 small volume saves space to rent;
 humanized design to reduce employee fatigue intensity;
 programmable controller (PLC) control, English and Chinese double man-machine interface control;
